IOT Verified Device

Product summary

BG770A-GL is a 5G-ready ultra-compact LPWA module compliant with 3GPP E-UTRA Release 13/14 specification. The module supports LTE Cat M1 bands. Besides, it features ultra-low power consumption implemented by MIPS 5150 processor and integrated RAM and flash, which help reduce current consumption to rather low levels in various modes, including PSM, eDRX etc. It is further integrated with a GNSS engine that supports GPS and GLONASS systems and a cellular-based positioning engine that supports QuecLocator®.
BG770A-GL boasts a comprehensive hardware-based security feature - Integrated Security Elements (ISE). With an ultra-compact SMT form factor of 14.9 mm × 12.9 mm × 1.9 mm and a high integration level, the module enables integrators and developers to design applications easily leveraging its low power consumption and compact structure design. The BG770A-GL’s advanced LGA package allows for fully automated manufacturing required for large-scale applications. A rich set of Internet protocols, industry-standard interfaces and abundant functionalities extend the applicability of the module to a wide range of M2M applications, such as wireless POS, smart metering, tracking, wearable devices, and many more.

Product summary

• 3GPP LTE Release 14/15 Cat M1, NB1 and NB2 LGA module
• Global band support: Single-SKU design (617 MHz to 2.2 GHz)
• Output power: +23dBm, +20dBm and +14dBm
• Supports external SIM, eSIM, integrated SIM, integrated eSIM
• Embedded LWM2M client, TCP/IP stack, and Sequans Cloud Connector™
• Application MCU with SDK
• Extensive list of antennas with technical certification is available.

Product summary

・ Multi-band LTE-M / NB-IoT module (Global Band supported)
・ Small and Optimized ultra-low power consumption
・ End-to-end security with a hardware-based Root of Trust (RoT)
・ Embedded LwM2M device management, MQTT and MQTT-SN supported
・ Important firmware updates can be delivered by uFOTA client / server solution
・ Ultra-high failure resistance against momentary power interruption
・ Integrated u-blox M8 chip GNSS receiver for accurate and reliable positioning anytime, anywhere concurently (BeiDou, Galileo, GLONASS, GPS, QZSS supported)

Product summary

• 3GPP LTE Release 14/15 Cat M1, NB1 and NB2 LGA module
• Global band support: Single-SKU design (617 MHz to 2.2 GHz)
• Output power: +23dBm, +20dBm and +14dBm
• Supports external SIM, eSIM, integrated SIM, integrated eSIM
• Embedded LWM2M client, TCP/IP stack, and Sequans Cloud Connector™
• Application MCU with SDK

Product summary

The ME910G1-WW has pin-to-pin compatibility with other members of Telit’s best-selling xE910 family. This heritage enables integrators to port their existing xE910-based designs quickly and cost-effectively to the ME910G1-WW. It is ideal for applications such as smart metering, security & surveillance, point of sales, health monitoring, fleet management, asset tracking and wearable devices.

• 28 x 28 x 2.2mm LGA form factor
• LTE UE Cat M1 (1.4 MHz)/NB2 (200 KHz)
• Data rate up to 588 Kbps DL/1Mbps UL for LTE Cat M1, 120 Kbps DL/160 Kbps UL for LTE Cat NB2
• 3GPP Rel. 14 compliant
• Single Rx/single antenna
• PSM and eDRX support for battery life
• Embedded GNSS (GPS/GLONASS/Beidou/Galileo)
• OMA Lightweight M2M (LwM2M)
• Firmware Over-the-Air Update (FOTA) using delta upgrade techniques
