IOT完了製品

製品概要

NetPrisma LCUR57-WWD is an LTE Advanced Category 16 module. Adopting the 3GPP Release 14 technology, it delivers speed of 1.0 Gbps downlink and 150 Mbps uplink peak data rates, and is designed in M.2 form factor.

製品概要

NetPrisma LCUK54-WRD is an LTE Advanced Category 6 module. Adopting the 3GPP Release 12 technology, the module supports a theoretical peak data rate of 300 Mbps in the downlink and a theoretical peak data rate of 50 Mbps in the uplink. Designed in M.2 form factor.

製品概要

・ マルチモード LTE Cat.4 データモジュール（グローバルバンド対応）
・ 小型超低消費電力
・ ルート・オブ・トラスト、セキュア・ブート、セキュア・アップデート、セキュア通信機能を備えたセキュア・バイ・デザイン
・ uFOTAクライアント / サーバー・ソリューションによる重要なファームウェアアップデート配信可能
・ ユーブロックスでは、市場のモジュール メーカーの中で最も広範なセルラー SEP (標準必須特許)をカバーしています。

製品概要

SC681A-JP is Quectel’s new generation of multi-mode Smart LTE Cat 6 module with built-in Android OS. Based on Qualcomm octa-core and 64-bit ARM v8.0 compliant application processor with built-in AdrenoTM 610 GPU, the module is designed to support high performance, various multimedia features and Quick Charge 3.0 technology. It is ideal for both industrial and consumer applications with high data rate and multimedia functions.
SC681A-JP supports multiple-input multiple-output (MIMO) technology. The use of multiple antennas at the receiver end on the same frequency band greatly minimizes errors and optimizes the data speed. This module also combines high-speed wireless connectivity with embedded dual-band multi-constellation and high-sensitivity GNSS (GPS/ GLONASS/ BDS/ Galileo/ NavIC/ QZSS) receiver for positioning.
A rich set of interfaces (such as LCM, Camera, Touch Panel, MIC, SPK, UART, USB, I2C, SPI) extend the applicability of the module to a wide range of M2M applications, including smart POS, smart cash registers, smart home gateways, smart robots, smart wearables, smart safety, PDA & tablets, vending machines, delivery lockers, audio & video recording equipment, video streaming and entertainment systems, etc.

製品概要

Product summary
It delivers 50Mbps upload and 150Mbps download data rates on LTE networks and can also be fully backward compatible with existing 3G networks
* LTE and WCDMA support
* LCC 30*30 Form factor/ MiniPCIE 51*31 package
* FoTA
* Control Via AT Commands according to 3GPP TS27.005, 27.007 and Gosuncn extended AT commands
* Drivers for WIN XP/7/8/10, Android, Linux, WinCE OS
* Support embedded TCP/UDP protocols, PAP and CHAP protocols used for PPP connection
