IOT Verified Device
-
- IOT Verified Device
PLS83-J Telit
Spceifications
| Supported Frequency | LTE: B1/3/8/18/19/26 5G: WCDMA: B1/6/8/19 |
|---|---|
| Category | Cat.4 |
| Supported Feature | Voice Call/Data Support |
| SIM Card | Compatible SIM for KDDI Network: - au Nano IC Card 04 - au Nano IC Card 04 LE |
Product summary
The PLS83-J wireless module features:
•LTE Cat.4, DL/UL max: 150Mbps / 50 Mbps
•3G fallback
•Embeded IP stack with IPv4 and IPv6 support
•Dimension: 33 x 29 x 2.5 mm
•Operating temperature Range -40°C to +85°
•Integrated GNSS support
•USB 2.0, UART, GPIO, I2C, ADC, Digital audio interface
•Firmware update via USB and ASC
Inquiries
Company Name: Telit Wireless Solutions Japan K.K.
Contact Person: Osamu Sato
Email: Osamu.Sato@telit.com
PLS63-W Telit
Spceifications
| Supported Frequency | LTE: B1/2/3/4/5/7/8/12/13/18/19/20/26/28/38/40/41/66 5G: WCDMA: B1/2/3/4/5/6/8/19 |
|---|---|
| Category | Cat.1 |
| Supported Feature | Voice Call/Data Support |
| SIM Card | Compatible SIM for KDDI Network: - au Nano IC Card 04 - au Nano IC Card 04 LE |
Product summary
The PLS63-W wireless module features:
•LTE Cat.1, DL/UL max: 10.2Mbps / 5.2 Mbps
•3G and 2G fallback
•Embeded IP stack with IPv4 and IPv6 support
•Dimension: 33 x 29 x 2.5 mm
•Operating temperature Range -40°C to +85°
•Integrated GNSS support
•USB 2.0, UART, GPIO, I2C, ADC, Digital audio interface
•Firmware update via USB and ASC
Inquiries
Company Name: Telit Wireless Solutions Japan K.K.
Contact Person: Osamu Sato
Email: Osamu.Sato@telit.com
PLS63-J Telit
Spceifications
| Supported Frequency | LTE: B1/3/8/18/19/26 5G: WCDMA: B1/6/8/19 |
|---|---|
| Category | Cat.1 |
| Supported Feature | Voice Call/Data Support |
| SIM Card | Compatible SIM for KDDI Network: - au Nano IC Card 04 - au Nano IC Card 04 LE |
Product summary
The PLS63-J wireless module features:
•LTE Cat.1, DL/UL max: 10.2Mbps / 5.2 Mbps
•3G fallback
•Embeded IP stack with IPv4 and IPv6 support
•Dimension: 33 x 29 x 2.5 mm
•Operating temperature Range -40°C to +85°
•Integrated GNSS support
•USB 2.0, UART, GPIO, I2C, ADC, Digital audio interface
•Firmware update via USB and ASC
Inquiries
Company Name: Telit Wireless Solutions Japan K.K.
Contact Person: Osamu Sato
Email: Osamu.Sato@telit.com
NL668-JP-05, NL668-JP-05 MiniPCIe Fibocom Wireless Inc.
Spceifications
| Supported Frequency | LTE Band:1/3/8/11/18/19/21/26/28/41 |
|---|---|
| Category | Cat.4 |
| Supported Feature | Voice Call/Data Support |
| SIM Card | au Nano IC Card 04 au Nano IC Card 04 LE |
Product summary
NL668-JP module is LTE wireless communication module. It supports LTE-TDD/LTE-FDD/WCDMA modes in 10 frequency bands, as well as hybrid FDD/TDD LTE networks, with a downlink rate up to Cat4 150Mbps and an uplink rate 50Mbps. Fibocom NL668 can be used in industrial routing, security, Internet of Vehicles and other industries.
Inquiries
Fibocom Wireless Inc.
Asia Pacific Sales Dept.
Hideo Terai
japan_sales@fibocom.com
+81-80-2460-5707
SLM750,SLM750 MiniPCIe MeiG Smart Technology Co., Ltd MeiG Smart Technology Co., Ltd
.png)
Spceifications
| Supported Frequency | LTE: B1, B3, B8, B18, B19, B26, B28,B39, B41 WCDMA: B1,B6,B8,B19 |
|---|---|
| Category | Cat.4 |
| Supported Feature | Data Only |
| SIM Card | au Nano IC Card 04 au Nano IC Card 04 LE |
Product summary
The SMART SLM750 series is a global mode 4G M2M communication module product, which can cover the DOMESTIC LTE network and the LTE network of major operators around the world, with a downlink rate of 150Mbps and an uplink rate of 50Mbps. At the same time, it is downlink compatible with the existing 3G and 2G network, so as to ensure network communication even in remote areas.
Inquiries
Company name：MeiLink Co., Ltd.
TEL：0467-33-8020
E-mail: sales@meilink-jcv.com
MLP31-W Telit
Spceifications
| Supported Frequency | LTE: B1/2/3/4/5/7/8/12/13/14/17/18/19/ 20/25/26/28/29/30/32/38/39/40/41/42/ 43/46/48/66 WCDMA: B1/2/4/5/6/8/9/19 |
|---|---|
| Category | Cat.16 |
| Supported Feature | Data Only |
| SIM Card | au Nano IC Card 04 au Nano IC Card 04 LE |
Product summary
- High-Speed LTE Cat.16 and 3G Fallback
- M.2 data card with USB3.0
- Extended Temperature range
- GNSS supporting GPS, Glonass, Beidou and Galileo
- Global coverage and multi MNO support on one single SKU
- Embedded eSIM support for Windows10/11 and Android
Inquiries
Company Name: Telit Wireless Solutions Japan K.K.
Contact Person: Osamu Sato
Email: Osamu.Sato@telit.com
MLA31-W Telit
Spceifications
| Supported Frequency | LTE: B1/2/3/4/5/7/8/12/13/14/17/18/19/ 20/25/26/28/29/30/32/38/39/40/41/66 WCDMA: B1/2/4/5/6/8/9/19 |
|---|---|
| Category | Cat.9 |
| Supported Feature | Data Only |
| SIM Card | au Nano IC Card 04 au Nano IC Card 04 LE |
Product summary
- High-Speed LTE Cat.9 and 3G Fallback
- M.2 data card with USB3.0
- Extended Temperature range
- GNSS supporting GPS, Glonass, Beidou and Galileo
- Global coverage and multi MNO support on one single SKU
- Embedded eSIM support for Windows10/11 and Android
Inquiries
Company Name: Telit Wireless Solutions Japan K.K.
Contact Person: Osamu Sato
Email: Osamu.Sato@telit.com
ME3630-J2A V2A Gosuncn
Spceifications
| Supported Frequency | LTE: B1,B3,B8,B18,B19 WCDMA: B1,B6,B8,B19 |
|---|---|
| Category | Cat.4 |
| Supported Feature | Data Only |
| SIM Card | au Nano IC Card 04 au Nano IC Card 04 LE |
Product summary
FDD/WCDMA/TD-SCDMA/EV-DO/CDMA/GSM, the downlink speed is up to 150Mbps
* Chinese, European and US version
* LTE and WCDMA support
* Support GNSS
* LCC 30*30 Form factor
* FoTA
* Control Via AT Commands according to 3GPP TS27.005, 27.007 and ZTEWelink extended AT commands
* Drivers for WIN XP/7/8/10, Android, Linux, WinCE OS
* Support embedded TCP/UDP protocols, PAP and CHAP protocols used for PPP connection
Inquiries
WelinkJapan株式会社
徐東升
08034000086
jotoushou@welinkjapan.co.jp
EM05-G Quectel
Spceifications
| Supported Frequency | LTE:B1/2/3/4/5/7/8/12/13/14/18/19/20/ 25/26/28/38/39/40/41/66/71 WCDMA:B1/2/4/5/6/8/19 |
|---|---|
| Category | Cat.4 |
| Supported Feature | Data Only |
| SIM Card | au Nano IC Card 04 au Nano IC Card 04 LE |
Product summary
Quectel EM05-G is LTE category 4 module optimized specially for M2M and IOT applications.
Adopting the 3GPP Rel. 4 LTE technology, it delivers M2M-optimized speeds of 150Mbit/s downlink and 50Mbit/s uplink peak data rates.
Designed in the M.2 form factor.
Inquiries
Quectel Wireless Solutions Co., Ltd.
Yasuyuki Okada
japan-sales@quectel.com
AMM5500 AM Telecom co., ltd.
Spceifications
| Supported Frequency | LTE: B1/2/3/4/5/7/8/9/12/17/18/19/20/26 UMTS：B1/2/4/5/6/8/19 GSM：850/900/1800/1900MHz |
|---|---|
| Category | LTE Cat.4 |
| Supported Feature | Data Only |
| SIM Card | Size: - Compatible SIM for KDDI Network: - au Nano IC Card 04 - au Nano IC Card 04 LE |
Product summary
· LTE/UMTS/GSM M.2 Module
· Chipset: MDM9207
· Interface: Power IN, USB 2.0, UART, UICC, GPIO, Antenna, Ethernet, WLAN Interface
· LTE Cat.4(150/50Mbps), AT Command, FOTA, Data Service
Inquiries
AM Japan Co., Ltd.
Nobuhisa Tsuchimoto
Tel : +81-(0)3-6257-3834
Email : amjapan@amtel.co.jp
